Thiết bị đo lường ngành nước
Chia sẻ tài liệu kỹ thuật về Thiết bị đo lường ngành nước, bao gồm datasheet, manual...
Trong trường hợp, không tìm thấy tài liệu bạn cần, vui lòng liên hệ Envimart.
Thiết bị đo mực nước
Xem tất cảThiết bị đo lưu lượng nước
Xem tất cảThiết bị kết nối và hiển thị
Xem tất cả
con::cube_V3_EN S::CAN Datasheet
Free preview
con::cube V3
∙ s::can high-end IoT (Internet of Things) terminal based on an industrial PC, IP65
∙ widescreen color graphical display (9”) and touch screen
∙ highly intuitive use, informative visualization & easy operation: time series, optical spectra and all events in clear text
∙ sensor and station management of up to 64 parameters: automatic cleaning, data logging, sample & calibration including history and multipoint calibration, sensor function check, user management and easy data transfer via USB-stick
∙ low power operation with less than 3 watts (@ 15 min. measuring interval): wide range AC and DC variants available
∙ IoT (Internet of Things) and M2M (Machine to Machine) connectivity: 100 Mb/s Ethernet, 300 Mb/s WLAN and optional worldwide WCDMA 4G interface, remote control (http) and data transfer into “Cloud” via FTP, SSH and TML
∙ process interface to SCADA via Modbus RTU/TCP, SDI-12, Profibus DP, analog 0/4-20 mA and relay outputs (state)
∙ integration of third-party sensors via analog 0/4-20 mA and digital (solid state) inputs, Modbus RTU/TCP
∙ easily extendable & all moni::tool features available: 8 slots to customize I/Os, moni::tool software pre-installed, additional software features like online data validation and event detection optional
∙ s::can high-end IoT (Internet of Things) terminal based on an industrial PC, IP65
∙ widescreen color graphical display (9”) and touch screen
∙ highly intuitive use, informative visualization & easy operation: time series, optical spectra and all events in clear text
∙ sensor and station management of up to 64 parameters: automatic cleaning, data logging, sample & calibration including history and multipoint calibration, sensor function check, user management and easy data transfer via USB-stick
∙ low power operation with less than 3 watts (@ 15 min. measuring interval): wide range AC and DC variants available
∙ IoT (Internet of Things) and M2M (Machine to Machine) connectivity: 100 Mb/s Ethernet, 300 Mb/s WLAN and optional worldwide WCDMA 4G interface, remote control (http) and data transfer into “Cloud” via FTP, SSH and TML
∙ process interface to SCADA via Modbus RTU/TCP, SDI-12, Profibus DP, analog 0/4-20 mA and relay outputs (state)
∙ integration of third-party sensors via analog 0/4-20 mA and digital (solid state) inputs, Modbus RTU/TCP
∙ easily extendable & all moni::tool features available: 8 slots to customize I/Os, moni::tool software pre-installed, additional software features like online data validation and event detection optional
00:10
0
0
con::lyte_EN S::CAN Datasheet
Free preview
con::lyte
∙ s::can low-cost terminal designed for control applications
∙ power efficient LCD display and ergonomic user interface
∙ sensor and station management of up to 2 (eco) or 6 (pro) parameters
∙ control of automatic cleaning, data logging, sample & calibration, sensor function check and easy data transfer via USB-stick
∙ process interface to SCADA or con::cube via Modbus RTU, Profibus DP, analog 4-20 mA and relay outputs (state/PWM/Pulse)
∙ integration of third-party sensors via analog 0/4-20 mA input and digital (solid state/count) inputs
∙ outstanding control features: easy threshold and alarm limits with hysteresis, 3 optional PID or 2-point controllers
∙ certifications: CE, UL, CSA and RCM
∙ s::can low-cost terminal designed for control applications
∙ power efficient LCD display and ergonomic user interface
∙ sensor and station management of up to 2 (eco) or 6 (pro) parameters
∙ control of automatic cleaning, data logging, sample & calibration, sensor function check and easy data transfer via USB-stick
∙ process interface to SCADA or con::cube via Modbus RTU, Profibus DP, analog 4-20 mA and relay outputs (state/PWM/Pulse)
∙ integration of third-party sensors via analog 0/4-20 mA input and digital (solid state/count) inputs
∙ outstanding control features: easy threshold and alarm limits with hysteresis, 3 optional PID or 2-point controllers
∙ certifications: CE, UL, CSA and RCM
00:05
0
0
con::nect_V3 S::CAN Datasheet
Free preview
con::nect V3
∙ s::can connection device for one spectrometer V3 probe and one cleaning device
∙ expand con::cube/con::lyte sensors networks (longer distances and higher number of sensors)
∙ operation of one s::can spectrometer V3 probe
∙ RJ45 connector for wired network access
∙ s::can connection device for one spectrometer V3 probe and one cleaning device
∙ expand con::cube/con::lyte sensors networks (longer distances and higher number of sensors)
∙ operation of one s::can spectrometer V3 probe
∙ RJ45 connector for wired network access
00:05
0
0
ENVIDATA 1801 Inventia - Truyền dữ liệu quan trắc tự động
Free preview
Model: Envidata 1801
Hãng sản xuất: Inventia
Xuất xứ: Ba Lan
Dữ liệu được truyền về trung tâm theo phương thức FTP, file *.TXT theo thời gian có thể tùy chỉnh được
Khả năng kết nối với 6 ngõ vào analog (4-20mA)
Có 12 ngõ ra số sử dụng cho mục đích điều khiển (tín hiệu 24VDC), có thể sử dụng làm ngõ vào số
Có 16 ngõ vào số đa năng (có thể dùng đếm xung 250 Hz)
Có cổng kết nối Ethernet/ Modbus TCP master/slave
Kết nối RS485/RS232 Modbus RTU master/slave với các thiết bị ngoại vi
Chức năng gửi dữ liệu theo quy định TT 24/2017/TT-BTNMT
Tích hợp tính năng hiển thị trực tiếp lên màn hình HMI OLED graphic display (128x64 pixels)
Hãng sản xuất: Inventia
Xuất xứ: Ba Lan
Dữ liệu được truyền về trung tâm theo phương thức FTP, file *.TXT theo thời gian có thể tùy chỉnh được
Khả năng kết nối với 6 ngõ vào analog (4-20mA)
Có 12 ngõ ra số sử dụng cho mục đích điều khiển (tín hiệu 24VDC), có thể sử dụng làm ngõ vào số
Có 16 ngõ vào số đa năng (có thể dùng đếm xung 250 Hz)
Có cổng kết nối Ethernet/ Modbus TCP master/slave
Kết nối RS485/RS232 Modbus RTU master/slave với các thiết bị ngoại vi
Chức năng gửi dữ liệu theo quy định TT 24/2017/TT-BTNMT
Tích hợp tính năng hiển thị trực tiếp lên màn hình HMI OLED graphic display (128x64 pixels)
00:10
0
0
Thiết bị đo pH, ORP
Xem tất cả
redo::lyser_ww_EN S::CAN Datasheet
Free preview
redo::lyser
redo::lyser monitors ORP and temperature
redo::lyser pro: high temperature range
∙ s::can plug & measure
∙ measuring principle: unique, non-porous / non-leaking combined reference electrode for technically unrivalled and consistend ORP performance
∙ multiparameter sensor
∙ ideal for surface water, ground water and drinking water, also waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in flow cell
∙ operation via s::can terminals & s::can software
∙ plug connection or fixed cable
redo::lyser monitors ORP and temperature
redo::lyser pro: high temperature range
∙ s::can plug & measure
∙ measuring principle: unique, non-porous / non-leaking combined reference electrode for technically unrivalled and consistend ORP performance
∙ multiparameter sensor
∙ ideal for surface water, ground water and drinking water, also waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in flow cell
∙ operation via s::can terminals & s::can software
∙ plug connection or fixed cable
00:10
0
0
ph::lyser_ww_EN S::CAN Datasheet
Free preview
pH::lyser
pH::lyser eco monitors pH & temperature
pH::lyser pro: high temperature range
∙ s::can plug & measure
∙ measuring principle: unique, non-porous / non-leaking combined reference electrode for technically unrivalled and consistent pH performance
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ optional: automatic cleaning with compressed air
∙ plug connection or fixed cable
pH::lyser eco monitors pH & temperature
pH::lyser pro: high temperature range
∙ s::can plug & measure
∙ measuring principle: unique, non-porous / non-leaking combined reference electrode for technically unrivalled and consistent pH performance
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ optional: automatic cleaning with compressed air
∙ plug connection or fixed cable
00:10
0
0
ph::lyser_dw_EN S::CAN Datasheet
Free preview
pH::lyser
∙ s::can plug & measure
∙ measuring principle: unique, non-porous / non-leaking combined reference electrode for technically unrivalled and consistent pH performance
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ optional: automatic cleaning with compressed air
∙ plug connection or fixed cable
∙ s::can plug & measure
∙ measuring principle: unique, non-porous / non-leaking combined reference electrode for technically unrivalled and consistent pH performance
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ optional: automatic cleaning with compressed air
∙ plug connection or fixed cable
00:10
0
0
Thiết bị đo DO
Xem tất cả
oxi::lyser_ww_EN S::CAN Datasheet
Free preview
oxi::lyser™
oxi::lyser™ monitors disolved oxygen & temperature
∙ s::can plug & measure
∙ measuring principle: optical / fluorescence
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ automatic cleaning with compressed air
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ no flow necessary
∙ operation via s::can terminals & s::can software
∙ minimal maintenance (no consumables)
oxi::lyser™ monitors disolved oxygen & temperature
∙ s::can plug & measure
∙ measuring principle: optical / fluorescence
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ automatic cleaning with compressed air
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ no flow necessary
∙ operation via s::can terminals & s::can software
∙ minimal maintenance (no consumables)
00:10
0
0
Thiết bị đo TSS và độ đục
Xem tất cả
i::scan_dw_EN S::CAN Datasheet
Free preview
i::scan
i::scan monitors depending on the application an individual selection of: turbidity, TOC, DOC, UV254, UV254 f, color, UVT10, UVT10 f, UVT100 f and temperature
∙ s::can plug & measure
∙ turbidity: measurement according to EPA 180.1 and ISO 7027, 90° scattering (35 mm path length)
∙ new light emitting technology
∙ no consumables, no moving parts
∙ special, non-fouling optical window material
∙ low power consumption (less than 1 W typical)
∙ dual-beam compensated optics
∙ optional automatic cleaning compressed air (InSitu, only for version -075 with fixed cable) or autobrush
∙ long term stable, 100 % corrosion free
∙ plug connection or fixed cable
∙ 5000 hours maintenance free operation
∙ mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ can be mounted directly in a mains pipe / pressure pipe
∙ operation via s::can terminals & s::can software
i::scan monitors depending on the application an individual selection of: turbidity, TOC, DOC, UV254, UV254 f, color, UVT10, UVT10 f, UVT100 f and temperature
∙ s::can plug & measure
∙ turbidity: measurement according to EPA 180.1 and ISO 7027, 90° scattering (35 mm path length)
∙ new light emitting technology
∙ no consumables, no moving parts
∙ special, non-fouling optical window material
∙ low power consumption (less than 1 W typical)
∙ dual-beam compensated optics
∙ optional automatic cleaning compressed air (InSitu, only for version -075 with fixed cable) or autobrush
∙ long term stable, 100 % corrosion free
∙ plug connection or fixed cable
∙ 5000 hours maintenance free operation
∙ mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ can be mounted directly in a mains pipe / pressure pipe
∙ operation via s::can terminals & s::can software
00:10
0
0
soli::lyser_ww_EN S::CAN Datasheet
Free preview
soli::lyser
soli::lyser monitors TSS or MLSS
∙ s::can plug & measure
∙ measuring principle: optical (infrared absorbance)
∙ ideal for waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated (2 measuring ranges available)
∙ automatic cleaning with compressed air
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ minimal maintenance (no waste parts)
∙ most cost efficient sensor, cost of ownership are unmatched
soli::lyser monitors TSS or MLSS
∙ s::can plug & measure
∙ measuring principle: optical (infrared absorbance)
∙ ideal for waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated (2 measuring ranges available)
∙ automatic cleaning with compressed air
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ minimal maintenance (no waste parts)
∙ most cost efficient sensor, cost of ownership are unmatched
00:10
0
0
Thiết bị đo độ dẫn điện, độ mặn
Xem tất cả
condu::lyser_dw_EN S::CAN Datasheet
Free preview
condu::lyser
condu::lyser monitors conductivity, temperature & salinity*
∙ s::can plug & measure
∙ measuring principle condu::lyser: 4-electrode, direct-contact measurement
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ plug connection or fixed cable
condu::lyser monitors conductivity, temperature & salinity*
∙ s::can plug & measure
∙ measuring principle condu::lyser: 4-electrode, direct-contact measurement
∙ multiparameter sensor
∙ ideal for surface water, ground water, drinking water and waste water
∙ long term stable and maintenance free in operation
∙ factory precalibrated
∙ mounting and measurement directly in the media (InSitu) or in a flow cell
∙ operation via s::can terminals & s::can software
∙ plug connection or fixed cable
00:10
0
0
Thiết bị đo COD, BOD, TOC
Xem tất cả
ammo::lyser_eco_ww_EN S::CAN Datasheet
Free preview
ammo::lyser™ eco
ammo::lyser™ II eco: monitors NH4-N and temperature
ammo::lyser™ III eco+pH additionally monitors pH
ammo::lyser™ III eco+NO3-N additionally monitors NO3-N
ammo::lyser™ III eco+Cl- additionally monitors chloride
ammo::lyser™ IV eco+pH+NO3-N additionally monitors pH and NO3-N
ammo::lyser™ VI eco+pH+Cl- additionally monitors pH and chloride
∙ s::can plug & measure
∙ measuring principle: ISE (ionselective electrodes) - without potassium compensation
∙ multiparameter probe
∙ long term stable, factory precalibrated
∙ minimal maintenance, automatic cleaning with compressed air
∙ unique, non-porous / non-leaking reference electrode for technically unrivalled and consistent performance
∙ ISE refurbishment - the easy way to minimise maintenance
∙ easy & quick mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ automatic temperature compensation and pH compensation possible
∙ ideal for surface water, ground water, drinking water and waste water
∙ life time of ISE: typically 6 month (for applications <1mg/l NH4-N), resp. 1 to 2 years (for applications >1mg/l NH4-N)
∙ plug connection or fixed cable
ammo::lyser™ II eco: monitors NH4-N and temperature
ammo::lyser™ III eco+pH additionally monitors pH
ammo::lyser™ III eco+NO3-N additionally monitors NO3-N
ammo::lyser™ III eco+Cl- additionally monitors chloride
ammo::lyser™ IV eco+pH+NO3-N additionally monitors pH and NO3-N
ammo::lyser™ VI eco+pH+Cl- additionally monitors pH and chloride
∙ s::can plug & measure
∙ measuring principle: ISE (ionselective electrodes) - without potassium compensation
∙ multiparameter probe
∙ long term stable, factory precalibrated
∙ minimal maintenance, automatic cleaning with compressed air
∙ unique, non-porous / non-leaking reference electrode for technically unrivalled and consistent performance
∙ ISE refurbishment - the easy way to minimise maintenance
∙ easy & quick mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ automatic temperature compensation and pH compensation possible
∙ ideal for surface water, ground water, drinking water and waste water
∙ life time of ISE: typically 6 month (for applications <1mg/l NH4-N), resp. 1 to 2 years (for applications >1mg/l NH4-N)
∙ plug connection or fixed cable
00:10
0
0
carbo::lyser_V3_ww_EN S::CAN Datasheet
Free preview
carbo::lyser™ II / III - V3
carbo::lyser™ II monitors 2 of the following parameters: TSS, TS, TOC, DOC, BOD, COD, COD f, UV254 and UV254 f
carbo::lyser™ III monitors 3 of the follwing parameters: TSS, TOC, DOC, BOD, COD, COD f, UV254 and UV254 f
∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush
carbo::lyser™ II monitors 2 of the following parameters: TSS, TS, TOC, DOC, BOD, COD, COD f, UV254 and UV254 f
carbo::lyser™ III monitors 3 of the follwing parameters: TSS, TOC, DOC, BOD, COD, COD f, UV254 and UV254 f
∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush
00:10
0
0
spectro::lyser_V3_ww_EN S::CAN Datasheet
Free preview
spectro::lyser V3
spectro::lyser® UV-Vis monitors depending on the application an individual selection of: TSS, TS, turbidity, color, TOC, DOC, BOD, COD, NO3-N, NO3, HS-, O3, CLD, UV254, fingerprints, spectral alarms and temperature
∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ choose exactly the parameters you want to measure – unlimited number of parameters possible
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush/ruck::sack
spectro::lyser® UV-Vis monitors depending on the application an individual selection of: TSS, TS, turbidity, color, TOC, DOC, BOD, COD, NO3-N, NO3, HS-, O3, CLD, UV254, fingerprints, spectral alarms and temperature
∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ choose exactly the parameters you want to measure – unlimited number of parameters possible
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush/ruck::sack
00:20
0
0
multi::lyser_V3_ww_EN S::CAN Datasheet
Free preview
multi::lyser™ IV - V3
multi::lyser™ IV monitors 4 of the following parameters: TSS, TS, TOC, DOC, BOD, COD, COD f, NO3-N, UV254 and UV254 f
∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush
multi::lyser™ IV monitors 4 of the following parameters: TSS, TS, TOC, DOC, BOD, COD, COD f, NO3-N, UV254 and UV254 f
∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush
00:10
0
0
Thiết bị đo Amoni NH4+, Nitrate NO3-
Xem tất cả
AmmoLyt Datasheet WTW Xylem Datasheet
Free preview
Digital ISE sensor AmmoLyt® for ammonium
Ammonium measurement directly in the medium without sample preparation and sample transfer. Measurement of centrate and other process waters up to 2,000 mg/l NH4-N
Measuring method: Electrochemical
Appropriate Electrode: Reference electrode VARiON® Ref, Measuring electrode VARiON®Plus NO3, Compensation electrode VARiON®Plus Cl
Measuring range/Resolution
NH4-N: 1 ... 2,000 mg/l / 1 mg/l; 0.1 ... 100 mg/l / 0.1 mg/l
NH4+: 1 ... 2,580 mg/l / 1 mg/l; 0.1 ... 129.0 mg/l / 0.1 mg/l
Compensation Range: K+: 0.1 ... 1,000 mg/l / 0.1 mg/l
Measuring Accuracy in laboratory standard solutions
± 5 % of measured value ± 0.2 mg/l in standard solutions
Ammonium measurement directly in the medium without sample preparation and sample transfer. Measurement of centrate and other process waters up to 2,000 mg/l NH4-N
Measuring method: Electrochemical
Appropriate Electrode: Reference electrode VARiON® Ref, Measuring electrode VARiON®Plus NO3, Compensation electrode VARiON®Plus Cl
Measuring range/Resolution
NH4-N: 1 ... 2,000 mg/l / 1 mg/l; 0.1 ... 100 mg/l / 0.1 mg/l
NH4+: 1 ... 2,580 mg/l / 1 mg/l; 0.1 ... 129.0 mg/l / 0.1 mg/l
Compensation Range: K+: 0.1 ... 1,000 mg/l / 0.1 mg/l
Measuring Accuracy in laboratory standard solutions
± 5 % of measured value ± 0.2 mg/l in standard solutions
00:05
0
0
Alyza IQ_NH4 WTW Xylem Datasheet
Free preview
Alyza IQ NH4 WTW
Indophenol method according to DIN 38 406
Less Reagents - Minimized reagent consumption and waste
Simple Service - Minimum maintenance with automatic cleaning and calibration
Better Data - Reliable results from low to high measuring levels
Simple Service - Built with Service in mind, all service items can be quickly and easily exchanged without calling a service technician or service contracts.
Long Life Reagents - Easy and safe reagent replacement with no-drip reagent pouches
Clear Information - Clear measurement menu – even for 2 channel versions and monitoring of reagent life time.
Indophenol method according to DIN 38 406
Less Reagents - Minimized reagent consumption and waste
Simple Service - Minimum maintenance with automatic cleaning and calibration
Better Data - Reliable results from low to high measuring levels
Simple Service - Built with Service in mind, all service items can be quickly and easily exchanged without calling a service technician or service contracts.
Long Life Reagents - Easy and safe reagent replacement with no-drip reagent pouches
Clear Information - Clear measurement menu – even for 2 channel versions and monitoring of reagent life time.
00:20
0
0
ammo::lyser_pro_ww_EN S::CAN Datasheet
Free preview
ammo::lyser™ pro
ammo::lyser™ III pro monitors NH4-N and temperature
ammo::lyser™ IV pro+pH monitors NH4-N, temperature and pH
ammo::lyser™ IV pro+NO3-N monitors NH4-N, temperature und NO3-N
∙ s::can plug & measure
∙ measuring principle: ISE (ionselective electrodes) - with potassium compensation
∙ multiparameter probe
∙ long term stable, factory precalibrated
∙ automatic cleaning with compressed air
∙ easy & quick mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ ISE refurbishment - the easy way to minimise maintenance
∙ unique, non-porous / non-leaking reference electrode for technically unrivalled and consistent performance
∙ operation via s::can terminals & s::can software
∙ automatic temperature and potassium compensation, pH compensation possible
∙ ideal for surface water, ground water, drinking water and waste water
∙ minimal maintenance
∙ life time of ISE: typically 6 month (for applications <1mg/l NH4-N), resp. 1 to 2 years (for applications >1mg/l NH4-N)
∙ plug connection or fixed cable
ammo::lyser™ III pro monitors NH4-N and temperature
ammo::lyser™ IV pro+pH monitors NH4-N, temperature and pH
ammo::lyser™ IV pro+NO3-N monitors NH4-N, temperature und NO3-N
∙ s::can plug & measure
∙ measuring principle: ISE (ionselective electrodes) - with potassium compensation
∙ multiparameter probe
∙ long term stable, factory precalibrated
∙ automatic cleaning with compressed air
∙ easy & quick mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ ISE refurbishment - the easy way to minimise maintenance
∙ unique, non-porous / non-leaking reference electrode for technically unrivalled and consistent performance
∙ operation via s::can terminals & s::can software
∙ automatic temperature and potassium compensation, pH compensation possible
∙ ideal for surface water, ground water, drinking water and waste water
∙ minimal maintenance
∙ life time of ISE: typically 6 month (for applications <1mg/l NH4-N), resp. 1 to 2 years (for applications >1mg/l NH4-N)
∙ plug connection or fixed cable
00:10
0
0
Thiết bị đo Phosphate, Total Nitrogen, Total Phosphorus
Xem tất cả
MicC_uLFR HT DR - TP - Micromac Total Phosphorus - Systea Datasheet
Free preview
MICROMAC PHOSPHORUS TOTAL is a microprocessor controlled On Line analyzer specifically designed for automatic Total Phosphorous monitoring on several types of water matrix.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust LFA * hydraulics allows easy maintenance and long terms reliable operations.
* LFA: Loop Flow Analysis patent pending
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust LFA * hydraulics allows easy maintenance and long terms reliable operations.
* LFA: Loop Flow Analysis patent pending
00:10
0
0
Alyza IQ PO4 WTW Xylem Datasheet
Free preview
Alyza IQ PO4
Less Reagents - Minimized reagent consumption and waste
Simple Service - Regular maintenance takes just 10 minutes every 3 months
Better Data - Reliable results from low to high measuring levels
Simple Service - Built with Service in mind, all service items can be quickly and easily exchanged without calling a service technician or service contracts.
Long Life Reagents - Easy and safe reagent replacement with no-drip reagent pouches.
Clear Information - Clear measurement menu – even for 2 channel versions and monitoring of reagent life time
Less Reagents - Minimized reagent consumption and waste
Simple Service - Regular maintenance takes just 10 minutes every 3 months
Better Data - Reliable results from low to high measuring levels
Simple Service - Built with Service in mind, all service items can be quickly and easily exchanged without calling a service technician or service contracts.
Long Life Reagents - Easy and safe reagent replacement with no-drip reagent pouches.
Clear Information - Clear measurement menu – even for 2 channel versions and monitoring of reagent life time
00:20
0
0
MicC_uLFR HT FC - TN@220nm - Micromac Total Nitrogen - Systea Datasheet
Free preview
MICROMAC TOTAL NITROGEN is a microprocessor controlled On Line analyzer specifically designed for automatic Total Nitrogen monitoring on several types of water matrix.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications Micromac C ensures the highest level of robustness in the electronics, mechanics and hydraulics components. Complete separation between electronics and hydraulics plus a simple and robust LFA * hydraulics allows easy maintenance and long terms reliable operations.
*µLFR: µ Loop Flow Reactor - Patent pending
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications Micromac C ensures the highest level of robustness in the electronics, mechanics and hydraulics components. Complete separation between electronics and hydraulics plus a simple and robust LFA * hydraulics allows easy maintenance and long terms reliable operations.
*µLFR: µ Loop Flow Reactor - Patent pending
00:10
0
0
MicC_Phosphate - Micromac Phosphate - Systea Datasheet
Free preview
MICROMAC PHOSPHATE is a microprocessor controlled On Line analyzer specifically designed for automatic phosphate monitoring on several types of waters matrix.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust LFA * hydraulics allows easy maintenance and long terms reliable operations.
* LFA: Loop Flow Analysis patent pending
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust LFA * hydraulics allows easy maintenance and long terms reliable operations.
* LFA: Loop Flow Analysis patent pending
00:15
0
0
Máy phân tích kim loại nặng trong nước
Xem tất cả
MicCfa_Cyanide Total - Micromac Cyanide Total - Systea Datasheet
Free preview
MICROMAC CYANIDE TOTAL is a microprocessor controlled On Line analyzer specifically designed for automatic Cyanide monitoring on several types of water matrices.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust batch type CFA* hydraulics allows easy maintenance and long terms reliable operations.
*CFA: Continuous Flow Analysis
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust batch type CFA* hydraulics allows easy maintenance and long terms reliable operations.
*CFA: Continuous Flow Analysis
00:10
0
0
MicC_uLFR HT DR - TFe - Micromac Total Iron - Systea Datasheet
Free preview
MICROMAC TOTAL IRON is a microprocessor controlled On Line analyzer specifically designed for automatic Total Iron monitoring on several types of
waters matrix.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications Micromac C ensures the highest level of robustness in the electronics, mechanics and hydraulics components. Complete separation between electronics and hydraulics plus a simple and robust LFA* hydraulics allows easy maintenance and long terms reliable operations.
*LFA: Loop Flow Analysis patent pending
waters matrix.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications Micromac C ensures the highest level of robustness in the electronics, mechanics and hydraulics components. Complete separation between electronics and hydraulics plus a simple and robust LFA* hydraulics allows easy maintenance and long terms reliable operations.
*LFA: Loop Flow Analysis patent pending
00:10
0
0
MicC_Chromium6+ - Micromac Chromium 6+ - Systea Datasheet
Free preview
MICROMAC CHROMIUM HEX is a microprocessor controlled On Line analyzer specifically designed for automatic Chromium 6+ monitoring on several types of water matrices.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust LFA* hydraulics allows easy maintenance and long terms reliable operations.
*LFA: Loop Flow Analysis patent pending
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications ensures the highest level of robustness in the electronics, mechanics and hydraulics components.
Complete separation between electronics and hydraulics plus a simple and robust LFA* hydraulics allows easy maintenance and long terms reliable operations.
*LFA: Loop Flow Analysis patent pending
00:10
0
0
MicC_uLFR HT - TMn - Micromac Manganese Total - Systea Datasheet
Free preview
MICROMAC TOTAL MANGANESE is a microprocessor controlled On Line analyzer specifically designed for automatic Total Manganese monitoring on several types of water matrix.
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications Micromac C ensures the highest level of robustness in the electronics, mechanics and hydraulics components. Complete separation between electronics and hydraulics plus a simple and robust LFA* hydraulics allows easy maintenance and long terms reliable operations.
* LFA: Loop Flow Analysis patent pending
Technical Specifications
MEASURING PRINCIPLE: Colorimetric, Formaldoxine method, combined UV + HT digestion
COLORIMETER: dual beam, silicon detector
MEASUREMENT TYPE: cyclic; MEASURING INTERVAL: programmable
MEASURING TIME: 13-15 minutes depending on the ragem
MEASURING RANGE: 0-2 ppm Mn, other ranges available on request
DETECTION LIMIT: typically better 3% of the full scale, calculated as for EPA p. 136 appendix B
REPEATABILITY: better than 5%; SD% of 7 replicates at 50% of the full scale
ACCURACY: better than 5% 7 replicates at 20% of the full scale
OUTPUT SIGNAL: 4-20 mA INPUT SIGNALS: n. 1 Analysis, n. 1 calibration; digital contacts
ALARMS: n. 1 High Limit, n. 1 General, n. 1 Calibration; potential free contacts
SAMPLE AND WASTE DELIVERY: pressure free; SAMPLE TEMPERATURE: 10 °C- 30 °C
REAGENTS REPLACEMENT: 3/4 weeks depending on the operating temperature
PROTECTION: IP55
HARDWARE: PC104 industrial standard, Integrated keyboard and graphics display, RS232 option
POWER SUPPLY: 12 V DC external power supply included; 4W Standby; 50 W (mean) analysis
WEIGHT: 33 Kg without reagents; DIMENSION: 800x420x280 mm(hxwxd)
ROBUST AND RELIABLE
Designed for industrial and Environmental On Line applications Micromac C ensures the highest level of robustness in the electronics, mechanics and hydraulics components. Complete separation between electronics and hydraulics plus a simple and robust LFA* hydraulics allows easy maintenance and long terms reliable operations.
* LFA: Loop Flow Analysis patent pending
Technical Specifications
MEASURING PRINCIPLE: Colorimetric, Formaldoxine method, combined UV + HT digestion
COLORIMETER: dual beam, silicon detector
MEASUREMENT TYPE: cyclic; MEASURING INTERVAL: programmable
MEASURING TIME: 13-15 minutes depending on the ragem
MEASURING RANGE: 0-2 ppm Mn, other ranges available on request
DETECTION LIMIT: typically better 3% of the full scale, calculated as for EPA p. 136 appendix B
REPEATABILITY: better than 5%; SD% of 7 replicates at 50% of the full scale
ACCURACY: better than 5% 7 replicates at 20% of the full scale
OUTPUT SIGNAL: 4-20 mA INPUT SIGNALS: n. 1 Analysis, n. 1 calibration; digital contacts
ALARMS: n. 1 High Limit, n. 1 General, n. 1 Calibration; potential free contacts
SAMPLE AND WASTE DELIVERY: pressure free; SAMPLE TEMPERATURE: 10 °C- 30 °C
REAGENTS REPLACEMENT: 3/4 weeks depending on the operating temperature
PROTECTION: IP55
HARDWARE: PC104 industrial standard, Integrated keyboard and graphics display, RS232 option
POWER SUPPLY: 12 V DC external power supply included; 4W Standby; 50 W (mean) analysis
WEIGHT: 33 Kg without reagents; DIMENSION: 800x420x280 mm(hxwxd)
00:10
0
0
Máy lấy mẫu tự động
Xem tất cả
SP5B Maxx Autosampler Datasheet
Free preview
MAXX SP5 B
Fixed site sampler in plastic housing, especially suited for high ambient temperatures. For automatic sample extraction according to the vacuum principle. Mains operation 230V/50Hz.
Fixed site sampler in plastic housing, especially suited for high ambient temperatures. For automatic sample extraction according to the vacuum principle. Mains operation 230V/50Hz.
00:10
0
0
