EASYCHEM COLI ONLINE
MEASURING PRINCIPLE: Colorimetric (Total & Faecal Coliforms) and fluorimetric (E. coli)
MEASUREMENT TYPE: Fully automated, direct read, on-line discrete analyser for Presence/Absence (P/A) and Most Probable Number (MPN)
MEASUREMENT SENSITIVITY:
1 CFU / 100 mL (P/A)
1.8 – 1,250 up to 17,500 MPN /100 mL (MTF)
Other measurement ranges are programmable, according to the expected concentrations and the analytical frequency
MPN MEASUREMENT
FREQUENCY Up to 12 samples / day (Range depending on customer set-up)
MPN MEASUREMENT
TIME: 15-18 hours
MEASURING POINTS: One, multipoint as option
OPERATOR INTERFACE: Colour graphic touch-screen 15” display

ammo::lyser™ eco
ammo::lyser™ II eco: monitors NH4-N and temperature
ammo::lyser™ III eco+pH additionally monitors pH
ammo::lyser™ III eco+NO3-N additionally monitors NO3-N
ammo::lyser™ III eco+Cl- additionally monitors chloride
ammo::lyser™ IV eco+pH+NO3-N additionally monitors pH and NO3-N
ammo::lyser™ VI eco+pH+Cl- additionally monitors pH and chloride

∙ s::can plug & measure
∙ measuring principle: ISE (ionselective electrodes) - without potassium compensation
∙ multiparameter probe
∙ long term stable, factory precalibrated
∙ minimal maintenance, automatic cleaning with compressed air
∙ unique, non-porous / non-leaking reference electrode for technically unrivalled and consistent performance
∙ ISE refurbishment - the easy way to minimise maintenance
∙ easy & quick mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ automatic temperature compensation and pH compensation possible
∙ ideal for surface water, ground water, drinking water and waste water
∙ life time of ISE: typically 6 month (for applications <1mg/l NH4-N), resp. 1 to 2 years (for applications >1mg/l NH4-N)
∙ plug connection or fixed cable

carbo::lyser™ II / III - V3
carbo::lyser™ II monitors 2 of the following parameters: TSS, TS, TOC, DOC, BOD, COD, COD f, UV254 and UV254 f
carbo::lyser™ III monitors 3 of the follwing parameters: TSS, TOC, DOC, BOD, COD, COD f, UV254 and UV254 f

∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush

spectro::lyser V3
spectro::lyser® UV-Vis monitors depending on the application an individual selection of: TSS, TS, turbidity, color, TOC, DOC, BOD, COD, NO3-N, NO3, HS-, O3, CLD, UV254, fingerprints, spectral alarms and temperature

∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ choose exactly the parameters you want to measure – unlimited number of parameters possible
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush/ruck::sack

multi::lyser™ IV - V3
multi::lyser™ IV monitors 4 of the following parameters: TSS, TS, TOC, DOC, BOD, COD, COD f, NO3-N, UV254 and UV254 f

∙ measuring principle: UV-Vis spectrometry over the total range (190-750 nm)
∙ web server on board - IoT enabled, no user software is needed to configure the probe
∙ communicates directly with your mobile device via WLAN
∙ 8 GB onboard memory - capacity for logging data for many years
∙ improved optical performance - revolutionary precision
∙ fast measurement interval - every 10 seconds possible
∙ extremely power efficient - sleep mode for low energy consumption
∙ multiparameter probe with 1 mm, 5 mm or 35 mm optical path length, ideal for waste water, surface water and drinking water
∙ long term stable and maintenance free in operation
∙ factory precalibrated, local multi-point calibration possible
∙ automatic cleaning with compressed air or brush

i::scan
i::scan monitors depending on the application an individual selection of: TSS, COD, COD f, UV254, UV254 f, color, UVT10, UVT10 f and temperature

∙ s::can plug & measure
∙ new light emitting technology
∙ no consumables, no moving parts
∙ special, non-fouling optical window material
∙ low power consumption (less than 1 W typical)
∙ dual-beam compensated optics
∙ optional automatic cleaning compressed air (InSitu, only for version -075 with fixed cable) or autobrush
∙ long term stable, 100 % corrosion free
∙ plug connection or fixed cable
∙ 5000 hours maintenance free operation
∙ mounting and measurement directly in the media (InSitu) or in a flow cell (monitoring station)
∙ can be mounted directly in a mains pipe / pressure pipe
∙ operation via s::can terminals & s::can software
